Slurry Seal -SLXF0612

HomeSlurry Sealer/Micro Surfacing Paver

Slurry Seal -SLXF0612

> Chassis: HOWO 4*2
> Aggregate Bin Volume: 3-6m³
> Emulsion Tank Volume: 1.2m³
> Water Tank Volume: 1.2m³
> Paving Thickness: 3-15mm

Contact Us

E-mail

SLXF0612 Slurry Seal Application:

SLXF0612 Slurry Seal is mainly used for road surface common gaps, car marks, smooth surface, potholes and other problems of repair work. This vehicle can improve the friction and waterproof ability of the road surface. Reduce the smoothness of the road surface caused by long-term driving vehicles, the vehicle driving instability. And can reduce the washout of rainwater on the road, especially suitable for mountainous areas, rural narrow road construction work.

Practices show:

SELEAD All Slurry Seal Medel:


ModelSLXF0612SLXF1035SLXF1240SLXF1640 (Fiber type)SLXF1950 (Thick Pave)
ChassisHOWO 4*2HOWO 6*4HOWO/SHACMAN 8*4HOWO/SHACMAN 8*4HOWO/SHACMAN 8*4
Auxiliary Engine power70kw/2200rpm73kw/2400rpm75kw/2200rpm110 kw/2300rpm153kw/2300rpm
Aggregate bin volume3-6m310m312m313-16m319-22m3
Emulsion tank volume1.2m33.5 m34m34m35m3
Water tank volume1.2m33.5 m34m34m35m3
Additive tank volume400L400L400L400L
Stuffing Box Volume1×0.5 m32×0.5 m32×0.5 m32×0.5 m3 2×1 m3
Mixer outputMaximum 3.5T/minMaximum 3.5T/minMaximum 3.5T/minMaximum 3.5T/minMaximum4.5T/min
Minimum speedAround 1.5 km/hAround 1.5 km/hAround 1.0 km/hAround 1.0 km/hAround 1.0 km/h
Paving thickness3 ~ 15 mm3 ~ 15 mm3 ~ 15 mm3 ~ 15 mm3 ~ 60mm
Paving width1.6~2.5 m adjustable2.5~4.3 m adjustable2.5~4.3 m adjustable2.5~4.3 m adjustable2.5~4.3 m adjustable
Fiber cut length0.1%~0.25%0.1%~0.25%
Recommended fiber content12mm、24mm12mm、24mm
Dimensions7650*2300*3080mm10500*2500*3500mm11670*2520*3570mm12000*2550*3570mm12000*2550*3570mm

Road maintenance truck equipment has the function of laying pavement, sealing layer, filling potholes and so on. Through the hydraulic device and the stored material will be some problems of the road repair. The ground of the equipment is stable with sufficient power and small size. It can be applied to many road construction work.

SLXF0612 Slurry Seal Main Technical Features:

1、Howo customized chassis. The whole vehicle size is small and flexible. Very suitable for pavement construction in mountainous areas, rural areas, river channels, etc..
2、The ratio of asphalt and stone is automatically controlled, with precise proportioning and high degree of automation. The amount of material discharged during construction can be adjusted at any time according to the speed of the vehicle.
3、Innovative and improved mixing system, which makes the material mixing evenly and paving effect good.
4、The hydraulic system is of international famous brand, the operation of the equipment is more stable.
5、Full load of 5 cubic meters, economical and practical.
6、Simple operation, low daily maintenance cost.

Customer Case:

after-sale-service
